Technische Daten

Gerätetyp

Ethernet Switch

Formfaktor

Rackmontage 1U

Data Link Protokoll

Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management Protokoll

SNMP v1, v2c, SSH, HTTPS, CLI

Switching-Kapazität

8.8 Gbps

MAC Adresse

8000

Data Transfer Rate

1000 Mbps

Abmessungen (BxTxH)

44 x 22.8 x 4.3 cm

Gewicht

3.2 kg

Leistungsmerkmale

Autosensing, Autonegotiating, VLAN Support, Layer 2,
TACACS+, RADIUS Authentication, Jumbo Frames,
Spanning Tree Protocol, RSTP, Port Trunking, CoS,
IGMP Snooping, GVRP, Port Mirroring

Schnittstellen

24 x 10Base-T/100Base-TX - RJ45 Ports
2 x 1000Base- T/X Combo Module – RJ45/SFP Ports
1x Console Management RS232 Port
1 x Redundant PU 12VDC, 4.2A

Standards

IEEE 802.1D (STP)
IEEE 802.1p (CoS)
IEEE 802.1Q (VLANs)
IEEE 802.1w (RSTP)
IEEE 802.1X (Security)
IEEE 802.3 (Ethernet)
IEEE 802.3ad (Link Aggregation)
IEEE 802.3ab (1000BASE-T)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3x (Flow Control)
IEEE 802.3z (1000BASE-X)
EN 55022, UL 1950, FCC Part 15 Class A, EN 55024,
UL 60950, VCCI Class A, CE
