مادربرد ایسوس Mainboard Asus B75M-A

CPU
Intel Socket 1155 for 3rd/2nd Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors
Memory
2 x DIMM, Max. 16GB, DDR3 2200(O.C.)/2000(O.C.)/1800(O.C.)/1600/1333/1066 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
1600MHz and higher frequency is supported by Intel® 3rd generation processors.
Graphic
Integrated Graphics Processor
Multi-VGA output support : HDMI/DVI-D/RGB ports
Supports HDMI with max. resolution 1920 x 1200  60 Hz
Supports DVI-D with max. resolution 1920 x 1200  60 Hz
Supports RGB with max. resolution 2048 x 1536  75 Hz
Maximum shared memory of 1696 MB
Expansion Slots
1 x PCIe 3.0/2.0 x16
2 x PCIe 2.0 x1
1 x PCI
Storage
Intel B75 chipset :
5 x SATA 3Gb/s port, black
1 x SATA 6Gb/s port, black
LAN
Realtek 8111F-VB-CG, 1 x Gigabit LAN Controller
Audio
Realtek ALC887-VD 8-Channel High Definition Audio CODEC
Supports : Jack-detection, Multi-streaming, Anti-pop Function
USB Ports
Intel B75 chipset :
8 x USB 2.0 port (4 at back panel, , 4 at mid-board)
Intel B75 chipset :
4 x USB 3.0 port(s) (2 at back panel, 2 at mid-board
